200A Cable Accessory

200A Load Break Junctions

Material:EPDM
Rated Voltage:15kV
Rated Current:200A
Number of branches:2/3/4
Product description：Anhuang specialized in Loadbreak junctions, we supply high quality Loadbreak junctions. Our products accord with IEEE386, and IEC standards.
INQUIRY

200A Load break junctions are used in pad-mounted apparatus, underground vaults, and other apparatus to sectionalize, establish loops, taps, or splices, and to facilitate apparatus change outs. Sectionalizing a cable run to find and isolate a cable fault is made easy when a load break junction is used with 15kV class load break elbows. When mated with a comparably rated product, the junction provides a fully shielded, submersible, separable connection for load break operation. The body is molded of high quality EPDM.

Description	Reference No.	Number of branches
15kV 200A Load break junctions	AH MP2-15/200	2
15kV 200A Load break junctions	AH MP3-15/200	3
15kV 200A Load break junctions	AH MP4-15/200	4
